KHOLEE BLAST range of tungsten carbide blast nozzles are general purpose, durable blast nozzles suitable for a wide range of abrasive blasting applications.
Specially designed as a cost effective nozzle, kholee Blast nozzles are available with either a 32mm diameter or 25mm entry. Customers can also specify the inserts, the size of Bore diameter and length which suit different purpose. To ensure optimum life, all Blast Nozzles should always be sued with the appropriate nozzle gasket.
All KHOLEE BLAST nozzles including the long life, a choice of fine thread (1-1/4”, 32mm) or the coarse contractor thread (2”, 50mm) which provides quick release from the nozzle holder and avoiding grit entrapment. Optional on Aluminum outer jacket and PU outer jacket which protects the Venturi or Straight bore nozzle insert from damage.
◆ Specifications
| TC45 Series Nozzle |
| Model | Orifice | Length |
| TC45-5 | 8mm (5/16”) | 130mm (5-1/8”) |
| TC45-6 | 9.5mm (3/8”) | 130mm (5-1/8”) |
| TC45-7 | 11mm (7/16”) | 130mm (5-1/8”) |
| Tungsten carbide curvo-blast nozzle, 45 degree angle, aluminum 1-1/4” thread and outer jacket, tungsten carbide liner. |
| TC45-50 Series Nozzle |
| Model | Orifice | Length |
| TC45-5/50 | 8mm (5/16”) | 130mm (5-1/8”) |
| TC45-6/50 | 9.5mm (3/8”) | 130mm (5-1/8”) |
| TC45-7/50 | 11mm (7/16”) | 130mm (5-1/8”) |
| Tungsten carbide curvo-blast nozzle, 45 degree angle, aluminum 50mm (2”) contractor thread and outer jacket, tungsten carbide liner. |
◆ Features
●Optimized airflow control: The curved design guides airflow more precisely, ensuring uniform particle distribution and improving the uniformity and precision of sandblasting.
●Energy savings: By reducing airflow and material waste, the nozzle effectively improves work efficiency, thereby reducing energy consumption and lowering operating costs.
●Suitable for complex surfaces: The unique design allows it to easily handle complex and hard-to-reach surfaces, increasing the flexibility of sandblasting operations.
●High abrasion resistance: Made of abrasion-resistant materials, the nozzle can withstand prolonged high-intensity sandblasting work, extending its service life.
●Increased work efficiency: By increasing the sandblasting impact force and spray distance, operation time is significantly shortened, thereby improving overall work efficiency.
◆ Industry
◆ FAQ
How do Curved Blasting Nozzles improve sandblasting results?
Curved Blasting Nozzles precisely guide airflow through their curved design, ensuring even distribution of abrasive particles across the surface, thus improving the precision and consistency of the sandblasting effect. This design effectively enhances the efficiency of sandblasting operations, especially when dealing with complex and hard-to-reach surfaces, ensuring more uniform sandblasting.
What applications are Curved Blasting Nozzles suitable for?
Curved Blasting Nozzles are suitable for a variety of sandblasting operations, including metal cleaning, coating removal, rust removal, and casting surface finishing. Due to their excellent airflow control and high abrasion resistance, they are particularly suitable for fine machining and complex surface cleaning, providing higher sandblasting precision.
How to maintain Curved Blasting Nozzles?
When maintaining Curved Blasting Nozzles, regularly check the nozzles for blockages, wear, or cracks. After use, clean the inside of the nozzles to prevent material buildup from affecting airflow. Regularly check the wear of the nozzles, especially after heavy use. If significant wear or damage is found, replace them promptly to ensure sandblasting effect and long-term stable operation of the equipment.
