The Pneumatic Diaphragm Outlet Valve is a pneumatically driven diaphragm valve widely used for flow control of liquids, gases, particulate matter, and dust. Its core component is a flexible diaphragm, which is moved by a pneumatic actuator to control the opening and closing of the material flow. Compared to traditional valves, diaphragm valves offer better sealing performance and wear resistance, and can operate stably under various pressure conditions. This valve is commonly used in industries requiring precise flow control and rapid opening and closing, such as chemical, food, pharmaceutical, and mining industries.
The pneumatic operation of the Pneumatic Diaphragm Outlet Valve provides precise control, allowing for flow adjustment or shut-off of material flow according to actual needs, with a fast response time. The diaphragm structure not only prevents media leakage but also effectively handles the conveying of high-viscosity or particulate materials. Due to its simple structure, convenient maintenance, and high durability, it maintains excellent performance even under long-term, high-frequency operating conditions.

1/2” Diaphragm Outlet Valve
Model: TLR50-DOV   Size: 1/2”
Model: TLR100-DOV   Size: 1”

◆ Advantage

● Precise Control: Pneumatic drive provides precise flow regulation, ensuring accurate material control.
● Excellent Sealing: Diaphragm design guarantees high-efficiency sealing performance, preventing leakage and ensuring safe operation.
● Wear Resistance: Utilizing wear-resistant materials, it is suitable for handling high-viscosity or particulate materials, extending service life.
● Rapid Response: Pneumatic drive offers rapid response, suitable for applications requiring quick opening and closing, improving work efficiency.
● Simple Maintenance: Simple structure and few parts facilitate maintenance and replacement, reducing maintenance costs.

◆ Industry

◆ FAQ

How does a pneumatic diaphragm outlet valve work?
A pneumatic diaphragm outlet valve uses a pneumatic control device to drive the movement of a flexible diaphragm, controlling the opening and closing of fluids or materials. The pneumatic system provides pressure to the diaphragm according to a control signal, causing it to expand or contract, thereby precisely controlling the opening and closing of the valve to regulate or stop the flow of materials.


Which industries are suitable for pneumatic diaphragm outlet valves?
Pneumatic diaphragm outlet valves are widely used in chemical, pharmaceutical, food, mining, and paper industries. They are particularly suitable for applications requiring precise control of material flow, such as liquid flow control, gas conveying, and the handling of particulate matter or dust.


How to maintain a pneumatic diaphragm outlet valve?
When maintaining a pneumatic diaphragm outlet valve, regularly check the diaphragm for wear to ensure good sealing performance. Check the operating status of the pneumatic system to confirm that the air pressure is stable. If the diaphragm is found to be damaged or leaking, replace it promptly. Regularly clean the inside of the valve to prevent material accumulation and ensure the valve's normal operation.
