    Overhead Conveyor Shot Blasting Machines
    • Overhead Conveyor Shot Blasting Machines
    Continuous Overhead Conveyor shot blasting machines are among the most flexible types of blasting equipment, available semi automatic or fully automatic. The workpieces are suspended on hangers and carried into blasting chamber. They are used to remove rust, scale, sand and burrs from many kinds of work pieces such as castings, forgings, cylinder blocks, cylinder heads, tractor and diesel engine components and fabricated structures.Continuous overhead conveyor shot blasting machines are also used for the finishing blasting of sensitive work pieces or to roughen work piece surfaces for subsequent coating.

    As a rule, continuous overhead conveyor trail shot blasting machine are offered either for batch or continuous processing. In many cases, different processes such as blasting, painting and subsequent drying can be interconnected via the overhead conveyor system. This makes it possible to tap an enormous potential for streamlining the process workflow.


    The equipment is comprised of continuous overhead conveyor system, shot blasting chamber, blasting turbine, shots recycle system, dust removing system and electrical control system etc.



    ◆ Specifications

    CONTINUOUS OVERHEAD CONVEYOR SHOTBLASTINGMACHINES
    ModelKLQ383-4KLQ385-4KLQ483-4KLQ485-4KLQ4810-6
    Size of Product(mm)φ800x1200φ1000×1500Φ800×1200φ1000×1500φ1000×2500
    Qty of Working Station Qty2 2 2 2 2
    Overhead Conveyor MovingNon-stop Continuous MovingStep Moving
    Blasting Turbine(kg/min)4×2504×2504×2504×2506×250
    Max Hanger Loading(kg)300 500 300 500 1000
    Productivity(hook/hr)30~6030~6030~6030~6040~60
    Shots Recycle (t/h)60 60 60 60 90
    Blasting Chamber Size(mm)7680×2000
    x2900    		7680×2000
    x2900    		7680x2000
    x2900    		7680×2000
    x2900    		7680x2000
    x3800
    Total Air Rate Volume(m³/hr)17000 17000 17000 17000 19000
    Total Power(kw)Approx.75Approx.80Approx.75Approx.80Approx 115
