◆ Specifications
| POWER&FREETROLLEYOVERHEADCONVEYORSHOTBLASTINGMACHINE |
| Model | KLQ583-4 | KLQ585-6 | KLQ588-6 | KLQ5810-6 |
| Size of Product(mm) | φ800×1200 | φ800×1500 | 中550×2000 | φ1300×2600 |
| Qty of Working Station Qty | 2 | 2 | 2 | 2 |
| Overhead Conveyor Moving | Power and Free Trolley Overhead Conveyor |
| Blasting Turbine (kg/min) | 4×250 | 6×250 | 4×360 | 6×290 |
| Max Hanger Loading(kg) | 300 | 500 | 800 | 1000 |
| Productivity(hook/hr) | 40 | 50 | 50 | 30 |
| Shots Recycle(t/h) | 60 | 90 | 90 | 110 |
| Blasting Chamber Size(mm) | 7000x1800×2800 | 8500x1800x3500 | 7500x2300x3600 | 8500x2300 x4800 |
| Total Air Rate Volume (m³/hr) | 18500 | 18500 | 18500 | 22600 |
| Total Power(kw) | Approx.75 | Approx.145 | Approx.160 | Approx.170 |
◆ Advantages
● High Efficiency and Automation: This equipment combines power and a free-suspension rail conveyor system, enabling automated and efficient processing of large batches of workpieces, reducing manual intervention.
● Uniform Shot Peening: Workpieces move smoothly within the peening zone, ensuring that each workpiece surface receives shot peening evenly, achieving a consistent cleaning effect.
● Energy Saving and Environmental Protection: The abrasive used in this equipment is recyclable, reducing abrasive waste, and it does not use harmful chemical cleaning agents, meeting environmental standards.
● High Flexibility: Suitable for workpieces of various shapes, sizes, and weights, the conveyor system can be adjusted as needed to meet different production requirements.
● Enhanced Adhesion: The uniform roughness of the workpiece surface after shot peening helps improve the adhesion of coatings, paints, or anti-corrosion layers, enhancing the durability of the workpiece.
◆ Industry
◆ FAQ
What types of workpieces is the power-free trolley overhead conveyor shot blasting machine suitable for?
This shot blasting machine is suitable for various metal workpieces, especially large, complex-shaped parts, such as automotive parts, mechanical structural parts, castings, and welded components.
How to ensure the efficient operation of the shot blasting machine?
The key to ensuring efficient operation lies in regularly maintaining the equipment's transmission and blasting systems, maintaining the quality of the abrasive, and adjusting the blasting angle and speed to ensure the uniformity and consistency of the shot blasting process.
What safety measures should be taken when using this equipment?
Safety glasses, earmuffs, and dust masks should be worn during operation to avoid abrasive splashes. In addition, the electrical components, overhead rail system, and abrasive recovery device should be inspected regularly to ensure stable equipment operation and operator safety.
